Description
Power rating (kW) 17
Range of power rating (kW) 8 – 21
Diameter (mm) 200
Efficiency (%) ~ 80
CO emmision (per 13% O2) ≤ 0.09
Dust emmison* 35
Temperature (°C) 250
Weight (Kilo) 210
Length of wood (mm) 500
Fuel
Seasonal hardwood (humidity max 20%), brown coal
briquettes
Material boiler steel, Combustion chamber lined with acumotte
* mg/mn
3
** depends from the insulation of the building
MAXIMUM USE OF ENERGY
Made of high quality steel resistant to very high temperatures.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with Acumotte – heat accumulating material which raises the temperature in the combustion chamber.
High flue and smoke tube which are transversely located – increases the area of heat echange between the insert and the surrounding. Reducing the temperature of the gas exhaust helps to increase the efficiency of the device.
Fireplace’s doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 800oC.
CONVENIENT TO USE
Grateless fireplace insert – full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum. The bottom plate of the insert is significantly reduced relative to the door.
Double door opening system – lift up (Guillotine) and side opening. Lifted door makes loading of wood easier and machanism of side door opening allows to clean the glass.
Reduced soot deposition through a system of pure glass (air curtain).
MODERN DESIGN
A fireplace insert with two panes compiled with each other at angles (without brackets).
Decorative, heat-resistant glass that can withstand temperatures up to 800oC. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert. Doors are equipped with modern handle.
5 year warranty.
